ISO26262 ASIL-B/ASIL-D product certification
Certified functional safety library
Support for various functional safety certified compilers
Products
-
Raptor series
High performance automotive MCU, ASIL-B, born for intelligent control applications
The FC4150 family is a high-performance automotive MCU based on the Corex-M4F core, with built-in DSP instruction set, FPU, and 8KB instruction cache. Function safety ASIL-B rating, HSM with advanced security accelerator. Up to 150 MHz operating frequency and offer up to 2 MB Flash, 256 KB D-flash, and up to 256 KB SRAM with ECC. It integrates with a rich set of peripherals and advanced connectivity, one 10/100Mbps Ethernet with IEEE1588 and AVB, and six FlexCAN with optional CAN-FD and PNET support. AEC-Q100 qualified, Grade 1.
-
Rex series
Multiple ARM ® Cortex ®- M7 core with lockstep, high performance ASIL-D automotive HPU
The FC7300Fxx family is a high-performance automotive HPU (Hyper Processing Unit) based on multiple Cortex-M7 cores with lockstep, supporting the application of ASIL-D+ASIL-B function safety multi-core configurations. Up to 300 MHz operating frequency , 10 CAN-FD, 1 Gbit Ethernet with TSN function. Up to 8MB Flash and 1.1MB SRAM. The FC7300 family includes EVITA Full+ level HSM. AEC-Q100 qualified, Grade 1.
-
Pterosaur series
High computing performance, high performance and multiple lockstep cores ASIL-D automotive controller
Automotive grade DPU (Dynamic Processing Unit) based on multiple high-performance lockstep Cortex kernels, ASIL-D functional security. Up to 800 MHz operating frequency. It is an ideal chip for zonal control, safety handling, vehicle control, and intelligent driving applications.
-
Thunder Series
High security and high computing performance network communication processor, ASIL-D
High-performance, secure and reliable processor for service-oriented gateway, domain/zonal controller, and central compute applications.
-
Functional safety
-
AUTOSAR
Support AUTOSAR V4.3
Provide MCAL and configuration tools -
Security
HSM, EVITA FULL level
Compliant with China security standard also
Support security boot -
High performance
Multiple Cortex-M7 cores, 300MHz operating frequency
Large eFlash with multi bank support for full no-wait OTA
-
Quality service
All kinds of reference designs
Multiple technical support channels
-
High reliability
AEC-Q100 standard product certification
Full coverage of test items
More strict testing requirements than the AEC-Q100 standard
